2007-2014 Toyota FJ Cruiser Lower Bumper Mount LED Light Bar Kit Installation Guide

Check out the Toyota FJ Cruiser LED Light Bar (35-939a).

Step 1: Cut out the front mesh located at the lower bumper location to accommodate for the FJ Cruiser LED Light Bar.

Step 2: Open up the hood. We recommend removing the front bumper as well, so you can have easier access to install the LED light bar. Removing the front bumper is not required, but will definitely give you more room and hand space.

Step 3:
This is a close-up to show where you're going to mount the holding brackets. You will be securing the mounting brackets onto the singular screw.

Step 4: Now remove the bolt to expose the screw.

Step 5: Grab your LED light bar's metal mounting bracket. You will be mounting the the bracket via the hole indicated onto the exposed screw. Make sure you mount the bracket so that it faces outwards. Repeat the bracket mounting process on the other side.

Step 6: Bolt the FJ Cruiser LED light bar in between the mounting brackets and secure with nuts and washers.

Step 7: Connect the wires to power up the LED light bar.
