2014-up Lexus IS250 IS350 IS-F LED Interior Dome Map Light Package Installation Guide

You can find this product under Direct Fit Lexus IS250 IS350 Lexus IS Direct Fit LED Interior Lights Kit (LEXUS-IS-DF35).

1.) Using a small flat head screw driver, carefully pry open the front map light housing from the edge of the plastic clear lens. Start on one side and work your way to the other side, evenly prying it open.

2.) Once the lens is removed, you’ll see three (3) T10 incandescent bulbs. Remove those and set aside.

3.) Install the T10 adapters into the respective positions in the housing. Test the lights to make sure that they all work properly.

4.) Install the panel in place and re-install the clear plastic lens. You do not need to use the adhesive tape on the back of the panel as the lens will wedge the panel to the housing tightly.

5.) Move to the backseats and using the same flat head screw driver, carefully pry open the lens cover like how it was done with the front map lights.

6.) Once the lens has been removed, remove the three (3) incandescent bulbs in the housing.

7.) Install our T10 adapters into the respective positions inside the housing and test the lights to make sure that they all work properly.

8.) Install the panel in place and re-install the clear plastic lens. Again, you do not need to use the adhesive tape on the back as the clear lens tightly holds the panel in place. Enjoy your new Lexus IS250 LED Interior lights!
