Ford F250 F350 F450 LED Fog Light Kit Installation Guide

Check out the Ford F-250 F-350 LED Fog Light Kit

Step 1: Gain access to the back of the fog lamp location.



Step 2: Remove the existing fog lamp. Loosen the three screws behind the back support bracket and unplug the stock harness.



Step 3: Attach the metal mounting bracket onto the back support bracket. Use a screw, nut, and washer to secure both sides of the metal mounting bracket onto the back support piece. Make sure the bottom tail of the metal bracket is fixed behind the back support piece and then bolt in place.



Step 4: Mount the LED pod light onto the curved metal bracket.
Check out how to mount the LED pod light here:


Step 5: Now secure the LED pod light onto the horizontal flat portion of the metal mounting bracket. Use the screw, washer, and nut to tighten.



Step 6: Take the garnish bezel and attach it to the mounting bracket via the four holes on the outer edges of the bracket. The LED fog light assembly will peek out of the bezel slightly, just like the OEM fog lights. Secure the back mounting bracket onto your Ford F-Series truck via the top 2 silver holes and the bottom singular hole.



Step 7: Now wire up your new LED fog lights. Hardwire the wires on the LED fog lights to the stock harness adapter.

Step 8: Check to make sure everything works and enjoy your new Ford F-250 LED Fog Lights.
