Turn Signal Lights 3-PIN LED Flasher Relay Fix Installation Guide

You can find this 3-PIN LED Flasher Relay Fix (AA1184) here.

 Please keep in mind that this guide is meant to be a very general guide to provide you an idea/concept of how this product could be installed in your vehicle. Every vehicle is different and we recommend you do additional research prior to installation.

1) For most vehicles, the flasher relay is located inside the vehicle behind the steering column (you can also find it by turning on the turn signal lights and listen where is the clicking sound comes from). Remove the trim near where your fuse box is to locate the electrical components.

Universal Flasher Relay Installation

2) Locate the stock flasher relay and remove it circled in red. Again, keep in mind that your vehicle may differ in location and appearance of the stock flasher relay.

Universal Flasher Relay Installation

3) Compare the stock flasher relay and the CF13 3-Pin LED flasher side by side to make sure the prongs and polarity terminals on the bottom match up (negative on left and positive on right).

Universal Flasher Relay Installation

If your vehicle's stock flasher has positive on left and negative on right, you will need to purchase an extra CF14 conversion wire in additional.

 LED Relay Fix LED Turn Signal Corner Light

Replace the LED flasher relay and enjoy your new lights that do not hyper-flash with LED turn signals!

Universal Flasher Relay Installation

NOTES: Please keep in mind that this installation guide is meant to be used as assistance in installing these lights onto your vehicle. iJDMTOY is not responsible for any damages caused by improper installation or misuse of this guide
